Fiber Optic Cabling
Installation in
San Francisco

Single-mode (OS2) fiber has a much smaller core (9µm) that allows only one mode of light to propagate, eliminating modal dispersion and enabling extremely long distances (10km+) and very high bandwidth (100G+). It uses a 1310nm or 1550nm laser source. Single-mode is the right choice for inter-building connections, campus networks, and any run where distance or future bandwidth headroom is a priority.

Multimode (OM3/OM4) fiber has a larger core (50µm) that allows multiple light modes to travel simultaneously. It uses less expensive 850nm VCSEL light sources and supports 10G to 40G over distances up to 550 metres. Multimode is the most common choice for intra-building backbone, floor-to-floor riser, and data center horizontal connections in San Francisco. The active equipment (transceivers) is significantly cheaper for multimode wavelengths, which offsets the cable cost difference for moderate distances.

Yes — inter-building fiber is one of our most common projects in SF. The typical approach is to pull fiber through existing underground conduit between buildings if available, or install new conduit through a trench. In some cases, aerial fiber is an option between buildings on a private campus. For connections crossing public streets or sidewalks in San Francisco, encroachment permits from SFMTA or the relevant municipality are required — we handle this process.

We assess the underground conduit infrastructure during the site survey. San Francisco has extensive conduit networks between commercial buildings, particularly in the Financial District, SoMa, and established corporate campuses, but availability varies by location.

Yes. We troubleshoot and repair existing fiber plant throughout San Francisco. Common issues include: broken or cracked fibers (often from construction activity or accidental damage), contaminated connectors (the most common cause of intermittent fiber failures), bad splices from a previous installation, cable cuts during renovation work, and degraded links where bend radius was violated during installation.

Using our OTDR equipment we can locate any fault on a fiber run to within 1 metre, identify contaminated connectors, and characterise any splice or connector that is contributing excessive loss. Most fiber problems in SF commercial buildings are contaminated connectors — which can often be resolved same-day with a proper clean and re-test.

We work with all standard fiber connector types including LC (the most common in modern enterprise and data center applications), SC (widely used in telecommunications and legacy enterprise), ST (older installations, still found in many SF buildings built in the 1990s–2000s), FC (used in some telecommunications and test equipment), and MPO/MTP (high-density multi-fiber connectors used in data center pre-terminated trunk cables).

We can terminate any of these connector types, install pre-terminated cassettes and trunk cables, and convert between connector types using adapter plates or pigtail splices when required.

A single-building backbone installation (IDF to MDF, one or two floors) typically takes 1–2 days including termination, splicing, and OTDR testing. A multi-floor riser installation in a high-rise building typically takes 2–4 days. An inter-building campus installation with underground conduit work can take 3–7 days depending on distance, conduit conditions, and strand count.

Fusion splicing is precise work — we don’t rush it. We schedule realistic timeframes and communicate clearly if anything encountered during the installation (unexpected conduit conditions, building access issues) is going to affect the schedule.

Always install more strands than you need today. The incremental cost of additional fiber strands in a cable is small compared to the cost of pulling a second cable later. Our standard recommendation for a typical SF commercial building backbone is a minimum of 12 strands (6 active, 6 dark spare). For data center connections and high-bandwidth environments we recommend 24 or 48 strands. For inter-building campus runs we recommend 24–96 strands depending on the size of the campus and growth plans.

Dark fiber is cheap insurance. We’ve never had a client in San Francisco say they installed too much fiber — we’ve had many wish they’d installed more when they needed to add capacity.

Fiber optic installation in San Francisco typically costs more than copper cabling per run due to the precision termination and testing equipment required, but less per metre than copper for very long runs. A typical single-building backbone installation (4–12 fiber strands, one floor) runs $1,500–$4,000. A campus inter-building connection with underground conduit work, fusion splicing, and OTDR certification typically runs $3,000–$12,000+ depending on distance and strand count

Key factors affecting SF fiber costs include: whether existing conduit is available or new conduit needs to be installed, distance and number of splices required, strand count, fiber type (OM4 vs OS2), and access constraints in the building. We provide fixed-price quotes after a free site survey — no open-ended hourly billing.

OTDR stands for Optical Time Domain Reflectometer. It’s a fiber optic test instrument that sends a light pulse down the fiber and analyzes the reflections and backscatter to produce a “trace” — essentially an x-ray of the entire fiber run showing every event (splice, connector, bend, fault) and its precise location along the cable length.

OTDR testing is superior to a simple optical power meter test because it identifies where problems are, not just whether a problem exists. It measures insertion loss and reflection at every splice and connector, verifies continuity, and will identify a marginal splice or connector that is currently passing but likely to fail. ANSI/TIA-568.3-D requires OTDR testing for all installed optical fiber cabling. We perform bidirectional OTDR testing on every strand and deliver the trace files (.sor format) along with your test reports.
